Direct Wire Harness for ATOTO S8MS, A6PF & S8 Lite Head Units (Fits 2006-2012 Honda/Acura Vehicles)

Item Number: AHH-70-1722ATOTO-A6PF

Upgrade your Honda or Acura with an ATOTO S8 Lite, A6PF, or S8MS head unit using this ready-to-install harness. It comes pre-wired with an ATOTO connector on one end and a factory-style Honda/Acura plug on the other, ensuring a clean and hassle-free install. This kit also includes the AM/FM antenna adapter, so you won't need to purchase one separately. This version also includes steering wheel control wires (already connected for most applications). If you want to retain audio button functionality, you will need program these functions on the headunit screen. Upgrade your rig the right way!

Note: this adapter fits the 7-inch and 9-inch ATOTO A6 PF (A6G2A7PF, A6G2B7PF, A6G2C7PF, A6G209PF). It does NOT fit the 10.1-inch A6 PF (A6G110PF) - despite the A6 PF name that radio uses the standard ATOTO S8 & F7 connector, so it needs our other ATOTO adapter instead.

What's included:

• AM/FM radio adapter for the ATOTO unit
• Direct Wire Adapter - All Speaker signals are already wired. Just plug in both ends!

Installation:

1) Simply plug the direct wire harness into your ATOTO double-DIN or single-DIN head unit and the factory wiring connector of your Honda, Acura - no wire cutting or splicing required for installation.
2) For full functionality, the parking brake signal wire should be connected to ground (this is a separate wire on the headunit). This connection ensures proper navigation, safety lockout, and video playback controls on ATOTO stereos. The reverse signal wire is only necessary if you plan to install a backup camera, making this harness ideal for ATOTO head unit installs with rear view camera support.

Purchase:

Price: $34.00

Vehicle Fitment:

(If a known model is not listed, let us know)

Acura
2008-2012 RDX Non-Navigation
2013 RDX

Honda
2006-2011 CIVIC
2007-2011 CRV
2007-2008 FIT
2008-2010 ODYSSEY Non-Navigation

ATOTO A6PF and S8MS Headunit Compatibility

ATOTO uses 2 different headunit connectors. Please make sure you have the right one for the unit that you're installing!
ATOTO A5L 7-inch model - 7-inch ONLY, NOT the 10-inch A5L (A5LG110T / A5LG110PT), which uses the standard ATOTO S8 & F7 connector instead
ATOTO A6 PF model - 7-inch and 9-inch only (7-inch A6G2A7PF sold by AutoHarnessHouse HERE!) - NOT the 10.1-inch A6G110PF, see below
ATOTO S8 Lite model
ATOTO S8 MS model (9-inch S8G2094MS sold by AutoHarnessHouse HERE!) - except the S8G1104MS / S8EG1104MSB / S81104MSFX, see below
ATOTO S8 UN (S8G2A79UN)

DOES NOT FIT ATOTO F7WE or ATOTO F7 XE or any other ATOTO F7 Variations

DOES NOT FIT ATOTO X10

The ATOTO V10 (V10G110OC) and S8 Gen4 (S84G110PB) also use a 16-pin harness, but we have not yet confirmed they use this exact connector - please email us before ordering for one of those.

DOES NOT FIT the 10.1-inch ATOTO A6 PF (A6G110PF) - despite the A6 PF name, that radio uses the standard ATOTO S8 & F7 connector instead. Click here for the adapter that fits it.

DOES NOT FIT the ATOTO S8 MS sold as S8G1104MS, S8EG1104MSB or S81104MSFX - one radio, three part numbers depending on where you bought it (this is the 10-inch floating-screen S8 MS). That radio uses the standard ATOTO S8 & F7 connector instead. Click here for the adapter that fits it.

We carry a compatible adapter for these other ATOTO models. Please email us or check out the Similar items below.

Enon Headuint Compatibility

Eonon UA13SK Plus
Eonon UA12S-Plus

Power Acoustik Headunit Compatibility

Power Acoustik CP-71W
